Electrodiagram Multifungsi Monitor for medical use

7 inch high resolution color touch screen
12-lead simultaneous acquisition and display
ECG Automatic measurement and interpretation function
Complete digital filters, resisting baseline drift, AC and EMG interference
Compact and lightweight design
Support USB flash disk and micro SD card to extend memory
Software upgrade via USB/SD card
Built-in rechargeable Li-ion battery

Lead: Standard 12 leads
Acquisition Mode: Simultaneous 12 leads acquisition
Measurement Range: ±5mVpp
Input circuit: Floating; Protection circuit against Defibrillator effect
Input Impedance: ≥50MΩ
Input circuit current: <0.05µA
Record mode:
Automatic: 3CH×4+1R, 3CH×4, 3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2;
Manual: 3CH, 2CH, 3CH+1R, 2CH+1R;
Rhythm: Any lead selectable.
Filter
EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz
DFT Filter: 0.05 Hz/ 0.15 Hz
AC Filter: 50 Hz / 60Hz
CMRR
>100dB
Patient leak current
<10µA (220V-240V)
Frequency Response
0.05Hz~150Hz (-3dB)
Sensitivity
2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV (error:±5%)
Anti-baseline Drift
Automatic
Time constant
≥3.2s
Noise level
<15µVp-p
Paper speed
12.5 mm/s, 25 mm/s, 50 mm/s
Recording mode
Thermal printing system
Paper specification
Roll 80mmx20M
Safety Standard
IEC I/CF
Sample Rate
Normal: 1000sps/channel
Power Supply
AC: 100~240V, 50/60Hz, 30VA~100VA
DC: 14.8V/2200mAh, built-in lithium battery
